AWS CopilotでFocalboardをたててみる

% copilot --version
copilot version: v1.9.0

% ls
Dockerfile              LICENSE                 README.md               copilot                 docker-compose.yml

% copilot app init

  What would you like to name your application? [? for help] focalboard-app

Application name: focalboard-app
✔ Created the infrastructure to manage services and jobs under application focalboard-app..

✔ The directory copilot will hold service manifests for application focalboard-app.

% copilot env init

  What is your environment's name? [? for help] development

  Which credentials would you like to use to create development?  [Use arrows to move, type to filter, ? for more help]
    Enter temporary credentials
  > [profile default]
    [profile test]

  Would you like to use the default configuration for a new environment?
    - A new VPC with 2 AZs, 2 public subnets and 2 private subnets
    - A new ECS Cluster
    - New IAM Roles to manage services and jobs in your environment
  [Use arrows to move, type to filter]
  > Yes, use default.
    Yes, but I'd like configure the default resources (CIDR ranges).
    No, I'd like to import existing resources (VPC, subnets).

✔ Proposing infrastructure changes for the focalboard-app-development environment.
- Creating the infrastructure for the focalboard-app-development environment.  [create complete]  [88.7s]
  - An IAM Role for AWS CloudFormation to manage resources                     [create complete]  [24.6s]
  - An ECS cluster to group your services                                      [create complete]  [10.3s]
  - Enable long ARN formats for the authenticated AWS principal                [create complete]  [3.0s]
  - An IAM Role to describe resources in your environment                      [create complete]  [24.4s]
  - A security group to allow your containers to talk to each other            [create complete]  [5.6s]
  - An Internet Gateway to connect to the public internet                      [create complete]  [17.8s]
  - Private subnet 1 for resources with no internet access                     [create complete]  [16.7s]
  - Private subnet 2 for resources with no internet access                     [create complete]  [16.7s]
  - Public subnet 1 for resources that can access the internet                 [create complete]  [16.7s]
  - Public subnet 2 for resources that can access the internet                 [create complete]  [16.7s]
  - A Virtual Private Cloud to control networking of your AWS resources        [create complete]  [17.8s]
✔ Created environment development in region ap-northeast-1 under application focalboard-app.

% copilot svc init
Note: It's best to run this command in the root of your workspace.

  Which service type best represents your service's architecture?  [Use arrows to move, type to filter, ? for more help]
    Request-Driven Web Service  (App Runner)
  > Load Balanced Web Service   (Internet to ECS on Fargate)
    Backend Service             (ECS on Fargate)

  What do you want to name this Load Balanced Web Service? [? for help] focalboard-frontend

  Which Dockerfile would you like to use for focalboard-frontend?  [Use arrows to move, type to filter, ? for more help]
  > ./Dockerfile
    Enter custom path for your Dockerfile
    Use an existing image instead

Service type: Load Balanced Web Service
Service name: focalboard-frontend
Dockerfile: ./Dockerfile
Note: Architecture type arm64 is currently unsupported. Setting platform linux/amd64 instead.\nSee 'platform' field in your manifest.\n
✔ Wrote the manifest for service focalboard-frontend at copilot/focalboard-frontend/manifest.yml
Your manifest contains configurations like your container size and port (:8000).

✔ Created ECR repositories for service focalboard-frontend..

% ls copilot/focalboard-frontend
manifest.yml

% copilot svc deploy
Only found one service, defaulting to: focalboard-frontend
Only found one environment, defaulting to: development
Environment development is already on the latest version v1.5.1, skip upgrade.
[+] Building 9.0s (6/6) FINISHED
...
Use 'docker scan' to run Snyk tests against images to find vulnerabilities and learn how to fix them
Login Succeeded
Using default tag: latest
The push refers to repository
...
✔ Proposing infrastructure changes for stack focalboard-app-development-focalboard-frontend
- Creating the infrastructure for stack focalboard-app-development-focalboard-frontend  [create complete]  [269.8s]
  - Service discovery for your services to communicate within the VPC                   [create complete]  [1.5s]
  - Update your environment's shared resources                                          [update complete]  [148.9s]
    - A security group for your load balancer allowing HTTP and HTTPS traffic           [create complete]  [6.6s]
    - An Application Load Balancer to distribute public traffic to your services        [create complete]  [121.0s]
  - An IAM Role for the Fargate agent to make AWS API calls on your behalf              [create complete]  [25.6s]
  - A CloudWatch log group to hold your service logs                                    [create complete]  [1.5s]
  - An ECS service to run and maintain your tasks in the environment cluster            [create complete]  [59.1s]
    Deployments
               Revision  Rollout      Desired  Running  Failed  Pending
      PRIMARY  1         [completed]  1        1        0       0
  - A target group to connect the load balancer to your service                         [create complete]  [1.5s]
  - An ECS task definition to group your containers and run them on ECS                 [create complete]  [2.7s]
  - An IAM role to control permissions for the containers in your tasks                 [create complete]  [25.6s]
✔ Deployed focalboard-frontend, you can access it at http://xxxxxxxxxx.ap-northeast-1.elb.amazonaws.com.

% copilot app delete

  Are you sure you want to delete application focalboard-app? [? for help] (Y/n) y

Are you sure you want to delete application focalboard-app? Yes
✔ Deleted service focalboard-frontend from environment development..
✔ Deleted resources of service focalboard-frontend from application focalboard-app..
✔ Deleted service focalboard-frontend from application focalboard-app.
✔ Deleted environment development from application focalboard-app..
✔ Cleaned up deployment resources..
✔ Deleted application resources..
✔ Deleted application configuration..
✔ Deleted local .workspace file.
